6. COOLING SYSTEM
6-13
XCITING 500
RADIATOR
REMOVAL
Drain the coolant (page 6-6).
Remove the inner cover (page 2-14).
Remove the front lower cover (page 2-15)
Disconnect the fan motor connector.
Loosen the hose band and disconnect the
radiator lower hose from the radiator.
Loosen the hose band and disconnect the
coolant filler hose from the radiator.
Fan Moto
r
Filler Hose
Lower Hose
