6. COOLING SYSTEM

6-10

XCITING 500

INSTALLATION

Install the thermostat into the housing with

its air bleed hole facing up and aligning

bleed hole with the tab in the housing.

Install a new O-ring into the housing cover

groove.

Install the housing cover and housing stay

to the housing.

Tighten the bolts securely.

Install the housing stay to the frame.

Tighten the nut securely.

Fill the system with recommended coolant

and bleed the air (page 6-6).

WATER PUMP

MECHANICAL SEAL INSPECTION

Inspect the telltale hole for sign of coolant

leakage.

If there is leakage, the mechanical seal is

defective, and water pump should be

replaced

Air Bleed Hole

Tab Align

O-ring

Telltale Hole
