KYMCO XCITING 500 Service Manual

10. DRIVE AND DRIVEN PULLEY
10-0
XCITING 500
10
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
DRIVE AND DRIVEN PULLEY
__________________________________________________________________________________
SCHEMATIC DRAWING ------------------------------------------------- 10- 1
SERVICE INFORMATION------------------------------------------------ 10- 2
TROUBLESHOOTING----------------------------------------------------- 10- 2
LEFT CRANKCASE COVER--------------------------------------------- 10- 3
DRIVE PULLEY ------------------------------------------------------------ 10- 5
CLUTCH/DRIVEN PULLEY---------------------------------------------- 10-13
10

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
