20. LIGHTS/METERS/SWITCHES

20-7

XCITING 500

BRAKE LIGHT SWITCH

Remove the upper handlebar cover (page 2-5).

Disconnect front or rear light switch connector

and check for continuity between the switch

terminals.

There should be continuity with the front or rear

brake lever squeezed, and there should be no

continuity with the front or rear brake lever is

released.

IGNITION SWITCH

INSPECTION

Remove the front cover (page 2-11).

Disconnect the ignition switch connector and

check for continuity at the switch side connector

terminals.

Continuity should exist between the color code

wires as follows:

Brake Light Switch

Connector Ignition Switch (Comb Switch)
