KYMCO XCITING 500 Service Manual

17. BATTERY/CHARGING SYSTEM
17-0
XCITING 500
17
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
BATTERY/CHARGING SYSTEM
__________________________________________________________________________________
CHARGING SYSTEM LAYOUT ---------------------------------------- 17-1
SERVICE INFORMATION------------------------------------------------ 17-2
TROUBLESHOOTING----------------------------------------------------- 17-4
BATTERY -------------------------------------------------------------------- 17-5
CHARGING SYSTEM INSPECTION ----------------------------------- 17-6
ALTERNATOR CHARGING COIL-------------------------------------- 17-7
REGULATOR/RECTIFIER------------------------------------------------ 17-8
17

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
