9. CYLINDER/PISTON
9-2
XCITING 500
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The cylinder and piston can be serviced with the engine installed in the frame.
• When installing the cylinder, use a new cylinder gasket and make sure that the dowel pins are
correctly installed.
• After disassembly, clean the removed parts and dry them with compressed air before inspection.
SPECIFICATIONS Unit: mm (in)
Ite
Service Limit
I.D. 92.005 (3.6802)～92.015 (3.6806) 92.1 (3.684)
Warpage
0.01 (0.0004)
0.05 (0.002)
Cylindricity
0.01 (0.0004)
0.1 (0.004)
True roundness
0.01 (0.0004)
0.1 (0.004)
Ring-to-groove top
0.03 (0.0012)～0.065 (0.0026) 0.08 (0.003)
clearance
Second
0.015 (0.0006)～0.05 (0.002) 0.065 (0.0026)
top
0.15 (0.006)～0.3 (0.012) 0.5 (0.02)
Piston, Ring end gap Second
0.03 (0.012)～0.45 (0.018) 0.65 (0.026)
piston ring Oil side rail
0.2 (0.008)～0.7 (0.028)
1 (0.04)
Piston O.D.
91.96 (3.6784)～91.98 (3.6793) 91.9 (3.676)
Piston O.D. measuring position
10 mm from bottom of skirt －
. Piston-to-cylinder clearance
0.01 (0.0004)～0.045 (0.0018) 0.1 (0.004)
Piston pin hole I.D.
22.002 (0.8801)～22.008 (0.8803) 22.04 (0.8826)
Piston pin O.D
21.994 (0.8798)～22 (0.88) 21.96 (0.8784)
Piston-to-piston pin clearance
0.002 (0.0001)～0.014 (0.0006) 0.02 (0.001)
Connecting rod small end I.D. bore
22.016 (0.8806)～22.034 (0.8814) 22.06 (0.8824)
TROUBLESHOOTING
• When hard starting or poor performance at low speed occurs, check the crankcase breather for
white smoke. If white smoke is found, it means that the piston rings are worn, stuck or broken.
Compression too low or uneven
compression Excessive smoke from exhaust muffler
• Worn or damaged cylinder and piston rings • Worn or damaged piston rings
• Worn, stuck or broken piston rings • Worn or damaged cylinder and piston
Compression too high Abnormal noisy piston
• Excessive carbon build-up in combustion • Worn cylinder, piston and piston rings
chamber or on piston head • Worn piston pin hole and piston pin
• Incorrectly installed piston
