KYMCO XCITING 500 Service Manual

18. IGNITION SYSTEM
18-0
XCITING 500
18
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
IGNITION SYSTEM
__________________________________________________________________________________
IGNITION SYSTEM LAYOUT------------------------------------------- 18-1
SERVICE INFORMATION------------------------------------------------ 18-2
TROUBLESHOOTING----------------------------------------------------- 18-2
IGNITION COIL INSPECTION ------------------------------------------ 18-4
IGNITION CONTROL MODULE ---------------------------------------- 18-5
18

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
