Lenze EVS9326-EK User Manual

Configuration
7-4

SHB9300CRV EN 2.0
7.3 Working with function blocks
You can configure the signal flow in the controller yourself, by connecting function blocks. The
controller can thus be easily adapted to diverse applications.
7.3.1 Signal types
Every function block has a number of inputs and outputs for connection. Corresponding to their
functions, there are only certain types of signals at the inputs and outputs:
l Quasi analog signals
–Symbol:L
–Unit:%
– Abbreviation: a
– Value range:  16384 =  100%
– Resolution: 16 bit
l Digital signals
–Symbol:P
– Unit: binary, with HIGH or LOW level
– Abbreviation: d
– Resolution: 1 bit
l Speed signals
–Symbol:
a
–Unit:rpm
– Abbreviation: phd
– Resolution: 16 bit
l Phase signals
–Symbol:▲
–Unit:inc
– Abbreviation: ph
– Resolution: 16 bit
Only the same types of signals can be connected. Thus, the analog output signal of one function
block canonlybe connected to the analog input of theother function block. If you tryto connect two
different signal types, the connection will be rejected.
