Configuration
7-10
SHB9300CRV EN 2.0
7.4 Change of the terminal assignments
(see also chapter 7.3 ”How to use function blocks”)
If the configurationischanged viaC0005, theassignment ofall inputsand outputswill beoverwritten
with the corresponding basic assignment. If necessary, the function assignment must be adapted
to the wiring.
Note!
Use the menu ”Terminal I/O” for the keypad 9371BB or the menu ”Terminal I/O” for Global Drive
Control or LEMOC2.
Stop!
To reassign an input, the signal source assigned before will not be overwritten! Remove all active
connections not wanted (see chapter 7.3.3).
7.4.1 Freely assignable digital inputs
There are 5 freely assignable digital inputs (X5/E1 ¡ X5/E5). It is possible to determine the polarity
for each input, i.e. the input is HIGH active or LOW active.
Change assignment:
Note!
Use the submenu ”DIGIN” for the keypad 9371BB or the submenu ”Digital inputs” for Global Drive
Control or LEMOC2.
