Function block library
7-128

SHB9300CRV EN 2.0
7.6.40 Free codes (FCODE)
2 x 16 free codes are available:
FCODE1476/1-16 and FCODE1477/1-16
Purpose
Input of length-related setpoints in physical units
Function
FCODE1476/1 -16
Input in [m_units]. (Measuring system of the master value)
FCODE1477/1 -16
Input in [s_units]. (Measuring system of the curve drive)
Stop!
The codes for the determination of the scaling factors (gearbox factors, feeding factors) affect the
conversion of the units in incremental values.
Master units: C1303/1; C1303/2; C1304
Slave units: C1305/1; C1305/2; C1306
