Function block library
7-97
 SHB9300CRV EN 2.0
7.6.27.1 Characteristic with two co-ordinates
Set C0960 = 1.
y
CURVE1-OUT
x
CURVE1-IN
C0961
C0964
100%
-C0961
-C0964
-100%
y0
y100
Fig. 7-67 Line diagram with 2 co-ordinates
7.6.27.2 Characteristic with three co-ordinates
Set C0960 = 2.
y
CURVE1-OUT
x
CURVE1-IN
C0961
C0962
C0964
C0965 100%
-C0961
-C0962
-C0964
-C0965
-100%
y0
y1
y100
x1
Fig. 7-68 Line diagram with three co-ordinates
