Configuration
7-287

SHB9300CRV EN 2.0
7.8.2.6 Password protection
Code LCD
Possible settings
IMPORTANT
C
o
d
e
L
C
D
Lenze Selection
I
M
P
O
R
T
A
N
T
C0094 Password 0 0 9999 Password
l Parameter access protection for the keypad. If
the password is activated, only codes of the
USER menu are made available. For further
selection possibilities see C0096
[C0096]
1
2
AIF protect.
CAN protect.
0
0
0Nopasswordprotection
1 Read protection
2 Write protection
3 Read/write protection
Extended password protection for bus systems
with activated password (C0094).
l Full access to codes in the user menu.
With password protection under C0094m the access to codes via keypad can be limited.
l Reading of C0094 with the keypad:
– C0094 = 0: Password protection is not activated.
– C0094 = 9999: Password protection is activated.
l Activate password protection:
– Enter a four digit number under C0094.
– Confirm input with SH + PRG.
l Deactivate password protection:
– Enter four digit number again.
– All other entries will be rejected.
Effect
l Working with the keypad:
– The codes of the USER menu can be read and changed.
– All other codes are no longer displayed.
l Working with the fieldbus:
– With C0096/1 (AIF) and C0096/2 (CAN) it is possible to extend the access protection for
fieldbus operation.
7.8.3 Display functions
Act. value display
The actual values can be read under the following codes:
Code Meaning
C0051 Absolute act. speed value [rpm]
C0052 Absolute motor voltage [V]
C0053 Absolute DC-bus voltage [V]
C0054 Absolute motor current [A]
C0060 Rotor position [inc/rev]
C0061 Heat sink temperature [

C]
C0063 Absolute motor temperature [

C]
Display only if the KTY (PTC) is connected via X7 or X8.
C0064 Controller load capacity [%]
Identification
l Read under C0099 which software version is used by the controller.
l C0093 indicates the controller type.
