Function block library
7-198

SHB9300CRV EN 2.0
7.6.64.5 Speed/dig. frequency input and output
The digital frequency/speed signal includes phase and speed information.
7.6.64.6 Connection of the function block
l
REFC-PSET provides the phase setpoint (contouring error)related to REFC-N-SET for the
phase controller in the function block MCTRL.
l
REFC-DFOUT includes phase and speed information. Connect this signal to CCTRL-IN.
