Lenze i510 User Manual

8 Drive Profile (Fieldbus)
Legacy Lenze Format
106 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
8.2 Legacy Lenze Format
This chapter describes the Legacy Lenze Format.
i
This Format was used in other Lenze products such as 8200Vector and 8400
8.2.1 Control word C135
0x400B:2 P592:2 Lenze Legacy C135 control word
Bits
Function
Comments
0
Setpoint Selection bit 0
Bits 0,1 decoding:
0 = Flexible (Default setpoint is active)
1 = Preset Setpoint #1
2 = Preset Setpoint #2
3 = Preset Setpoint #3
1
Setpoint Selection bit 1
2
Rotation (0-CW/1-CCW)
3
Activate quick stop
0 = Not Active
1 = Active
4
Reserved
5
Reserved
6
Reserved
7
Reserved
8
Reserved
9
Disable (1-active/0-inactiv)
0 = Controller released
1 = Controller Inhibited
10
Network user fault
11
Fault reset (01)
0->1 edge causes TRIP reset
12
Reserved
13
Reserved
14
DC Brake Active
0 = Not Active
1 = Active
15
Reserved
