5 Commissioning
Commissioning procedure
28 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
5.2 Commissioning procedure
Use the following table as a reminder that guides you through the commissioning procedure.
Step
Action
Information
1
Initial checks
 Check delivery for completeness.
 Check the nameplate information to ensure that you have the
correct type of inverter for your motor/application.
 Check for delivery damages. Don’t continue if your inverter
seems to be damaged!
 3.3 Typecode, page 16
2
Module assembly (only i550)
 Assembly your Control Unit (CU) on your Power Unit (PU) and
Safety Unit (Option)
 i500 Mounting and switch-on
instructions
3
Mechanical installation
 Install the inverter according to the instruction.
4
Electrical installation
 If you install the inverter to an IT network, remove the IT-
screws.
 Install the control wiring.
 Install motor and supply wiring in accordance to the EMC re-
quirements.
5
Functional test (if needed)
Perform a uncoupled functional test for basic test
6
General parameter setup
The i500 has linked the most common parameters to the favorites
menu. With these parameters most common basic application can
be solved.
 5.4 General parameter setup
(Favorites) page 29
7
Parameter setup (Auxiliary functions)
The i500 contains additional functions which can be used for more
complex applications.
 6 Function & parameter de-
scription, page 34.
8
Testrun & tuning
 Run the motor and check the performance of your application.
 Adjust the corresponding parameter to tune your application.
 6 Function & parameter de-
scription, page 34.
9
Diagnose & troubleshooting
Status LED and error messages are available for troubleshooting.
 9 Troubleshooting, page 117

Lenze i510 Specifications

General

Product Category	DC Drives
Series	i510
Protection Class	IP20
Communication	CANopen, Modbus RTU
Protection Features	Overvoltage, Undervoltage
Operating Temperature	-10 to +50 °C
Storage Temperature	-25 to +70 °C
Humidity	5% to 95% (non-condensing)
Control Mode	V/f control
