6 Function & parameter description
Group 1 – Diagnostics
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 43
6.3 Group 1 – Diagnostics
General:
Bit coded status words are displayed on the keypad as described in the following picture:
LOC REM MAN AUTO
b.0000.0000.0000.0000
SET8
LWX0000
LOC REM MAN AUTO
b.0000.0000.0000.0001
SET8
HWX0001
Bit 0Bit 15Bit 16
Bit 31
LOC REM MAN AUTO
b.0000.0000.0000.0100
SET8
X0004
Bit 0Bit 15
Hexadecimal Values
LW= Low Word
HW = High Word
Hexadecimal Values
Status word 16-bit
Status word 32-bit
Fig. 15: Display of bit coded status word on keypad
6.3.1 General Diagnostic Data
P100:0
0x2DDD:0
Actual frequency
i510
i550
R
-- ... [Actual value] ... -- Hz
Actual motor frequency
P101:0
0x400D:0
Scaled actual value
i510
i550
R
-- ... [Actual value] ... -- Units
Actual motor speed in user units.
Actual frequency x Scaling factor (P702:0)
P102:0
0x2B0E:0
Frequency setpoint
i510
i550
R
-- ... [Actual value] ... -- Hz
Actual frequency setpoint
P103:0
0x6078:0
Actual motor current
i510
i550
R
-- ... [Actual value] ... -- %
Actual motor current in % of P323:0
P104:0
0x2D88:0
Actual motor current
i510
i550
R
-- ... [Actual value] ... -- A
Actual motor current
P105:0
0x2D87:0
DC-bus voltage
i510
i550
R
-- ... [Actual value] ... -- V
Actual DC-Link voltage
P106:0
0x2D89:0
Actual motor voltage
i510
i550
R
-- ... [Actual value] ... -- VAC
Actual motor voltage
P107:0
0x6077:0
Actual torque
i510
i550
R
-- ... [Actual value] ... -- %
Actual motor torque (100% = Max. torque)
