8 Drive Profile (Fieldbus)
AC Drive Profile
110 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
8.3.2 Status word
0x400C:1 P593:1 AC Drive status word
Bits
Function
Comments
0
Fault/Trip
0 = No Fault
1 = Faulted
1
Warning active
2
Running forward (CW)
0 = Not running Forward
1 = Running Forward
3
Running reverse (CCW)
0 = Not running Forward
1 = Running Forward
4
Ready
0 = NOT Ready
1 = Ready
5
Control from Network
0 = Local Control
1 = Network Control
6
Reference from Network
0 = Local Reference
1 = Network Reference
7
At Reference
0 = Setpoint not reached
1 = Setpoint reached
8
Profile State bit0
9
Profile State bit1
10
Profile State bit2
11
Profile State bit3
12
PID active
0 = PID NOT Active
1 = PID Active
13
Torque mode active
0 = NOT in Torque Mode
1 = Torque Mode Active
14
Current Limit reached
0 = NOT in Current Limit
1 = in Current Limit
15
DC Brake Active
0 = DC brake NOT active
1 = DC brake active
