Lenze i510 User Manual

8 Drive Profile (Fieldbus)
NETword Configuration
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 115
8.4.2 NETWordOut configuration
Actual value:
P591:1
0x400A:1
NetWordOUT1
i510
i550
R
Bit # description:
0: Mapping bit 0
1: Mapping bit 1
…
Actual value of mappable network out word 1 bit collector
(Status bits)
--> Trigger mapping 0x2634:1-3 (P420:1-3)
P591:2
0x400A:2
NetWordOUT2
i510
i550
R
Bit # description:
0: Mapping bit 0
1: Mapping bit 1
…
No mapping
Configuration:
P420:10
0x2634:10
NETWordOUT1 - bit 0
i510
i550
R/W
51:Ready for operation
(Reference see P420:1)
Function of Network Bit 0
P420:11
0x2634:11
NETWordOUT1 - bit 1
i510
i550
R/W
0:Not connected
(Reference see P420:1)
Function of Network Bit 1 (SW 02.01: New Default)
P420:12
0x2634:12
NETWordOUT1 - bit 2
i510
i550
R/W
52:Inverter enable
(Reference see P420:1)
Function of Network Bit 2 (SW 02.01: New Default)
P420:13
0x2634:13
NETWordOUT1 - bit 3
i510
i550
R/W
56:Fault
(Reference see P420:1)
Function of Network Bit 3
P420:14
0x2634:14
NETWordOUT1 - bit 4
i510
i550
R/W
0:Not connected
(Reference see P420:1)
Function of Network Bit 4 (SW 02.01: New Default)
P420:15
0x2634:15
NETWordOUT1 - bit 5
i510
i550
R/W
54:Quick stop active
(Reference see P420:1)
Function of Network Bit 5
P420:16
0x2634:16
NETWordOUT1 - bit 6
i510
i550
R/W
50:Running
(Reference see P420:1)
Function of Network Bit 6 (SW 02.01: New Default)
P420:17
0x2634:17
NETWordOUT1 - bit 7
i510
i550
R/W
58:Device warning
(Reference see P420:1)
Function of Network Bit 7
P420:18
0x2634:18
NETWordOUT1 - bit 8
i510
i550
R/W
0:Not connected
(Reference see P420:1)
Function of Network Bit 8 (SW 02.01: New Default)
P420:19
0x2634:19
NETWordOUT1 - bit 9
i510
i550
R/W
0:Not connected
(Reference see P420:1)
Function of Network Bit 9 (SW 02.01: New Default)
P420:20
0x2634:20
NETWordOUT1 - bit 10
i510
i550
R/W
72:Setpoint speed reached
(Reference see P420:1)
Function of Network Bit 10

Lenze i510 Specifications

General

Product Category	DC Drives
Series	i510
Protection Class	IP20
Communication	CANopen, Modbus RTU
Protection Features	Overvoltage, Undervoltage
Operating Temperature	-10 to +50 °C
Storage Temperature	-25 to +70 °C
Humidity	5% to 95% (non-condensing)
Control Mode	V/f control
