Lenze i510 User Manual

8 Drive Profile (Fieldbus)
NETword Configuration
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 113
8.4.1 NETWordIn configuration
Actual value:
P590:1
0x4008:1
NETWordIN1
i510
i550
R/W
--
Actual value of mappable network in word 1 bit collector
(Trigger Function)
--> Trigger mapping 0x400E1-16 (P505:1-16)
P590:2
0x4008:2
NETWordIN2
i510
i550
R/W
--
Actual value of mappable network in word 2 bit collector
(Trigger for digital Outputs)
--> Trigger mapping 0x2634:1-3 (P420:1-3)
P590:3
0x4008:3
NETWordIN3
i510
i550
R/W
0.0 ... [0.0] ... 100.0 %
Actual value of mappable network in word 3
(Source for Analog Output 1 and 2)
--> Mapping 0x2639:2 (P440:2), 0x263A:2 (P441:2)
P590:4
0x4008:4
NETWordIN4
i510
i550
R/W
0.0 ... [0.0] ... 100.0 %
Actual value of mappable network in word 3
(Source for Analog Output 1 and 2)
--> Mapping 0x2639:2 (P440:2), 0x263A:2 (P441:2)
Configuration:
P505:1
0x400E:1
NETWordIN1.00
i510
i550
R/W
0: Not connected
1: Inverter disabled
2: Stop
3: Quick stop
4: Reset fault
5: DC brake
8: Run forward (CW)
9: Run reverse (CCW)
13: Invert rotation
14: AI1 setpoint selection
15: AI2 setpoint selection
17: Network setpoint selection
18: Preset bit0 selection
19: Preset bit1 selection
20: Preset bit2 selection
21: Preset bit3 selection
39: Ramp 2 selection
40: Load parameter set
41: Parameter set 1 selection
42: Parameter set 2 selection
43: User-Netw. fault 1
44: User-Netw. fault 2
45: Process controller off
46: Set PID output to 0
47: PID integrator disabled
48: PID influence ramps active
Function of Network Input Word Bit 0
P505:2
0x400E:2
NETWordIN1.01
i510
i550
R/W
0:Not connected
(Reference see P505:0)
Function of Network Input Word Bit 1

Lenze i510 Specifications

General

Product Category	DC Drives
Series	i510
Protection Class	IP20
Communication	CANopen, Modbus RTU
Protection Features	Overvoltage, Undervoltage
Operating Temperature	-10 to +50 °C
Storage Temperature	-25 to +70 °C
Humidity	5% to 95% (non-condensing)
Control Mode	V/f control
