6 Function & parameter description
Group 2 – Basic setup
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 55
P224:0
0x291B:0
Ramp time switch level
i510
i550
R/W
0.0 ... [0.0] ... 599.0 Hz
Switch point between ACC/DEC1 and ACC/DEC2:
Act frequency < Ramp time switch level (P224:0) --> Use Accel/Decel
time #1
Act frequency > Ramp time switch level(P224:0) --> Use Accel/Decel
time #2
0: Function Disabled
Note:
Selection of ACC/DEC by P400:39, PID ACC/DEC sequencer ACC/DEC,
Quickstops have higher priority
P226:1
0x291E:1
Smooth factor
i510
i550
R/W
0.0 ... [0.0] ... 100.0 %
Smothing factor for S-Shap characteristic ramping.
Note:
Smothing factor will extend ramp time:
50% --> 1,5 x configured ramp time
100% --> 2 x configured ramp time
6.4.9 Quickstop ramp time (QSP)
The inverter has an additional stopping method called “Quick Stop” (QSP) It works as a zero-speed or Pause func-
tion where the ramp time can be setup separately.
P225:0
0x291C:0
Quick stop decel. time
i510
i550
R/W
0.0 ... [1.0] ... 3600.0 s
Quick stop ramp time for the output frequency to decrease from Maxi-
mum frequency (P211:0) to 0.0 Hz
Note: In Cia402 Velocity mode (P301:0 = [2] Velocity mode (vl) ) the
quick stop deceleration time is defined by P790:0.
