6 Function & parameter description
Group 4 I/O setup
74 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
P400:19
0x2631:19
Preset selection bit 1
i510
i550
R/W
15:Digital input 5
(Reference see P400:1)
Preset frequency setpoint selection bit 1
P400:20
0x2631:20
Preset selection bit 2
i510
i550
R/W
0:Not connected
(Reference see P400:1)
Preset frequency setpoint selection bit 2
P400:21
0x2631:21
Preset selection bit 3
i510
i550
R/W
0:Not connected
(Reference see P400:1)
Preset frequency setpoint selection bit 3
6.6.3 Motor Potentiometer
With the motor potentiometer mode (MOP) the setpoint is controlled with the two triggers Increase and De-
crease (Example: 2 digital inputs).
The MOP is enabled by trigger P400:25 or can be set as default setpoint source.
Motor potentiometer up TRUE: Setpoint will increase with acceleration time 2
Motor potentiometer down TRUE: Setpoint will decrease with deceleration time 2
MOP is increasing/decreasing the setpoint according acceleration/deceleration time 2. The motor is following
the setpoint with acceleration/deceleration time 1 also in MOP-mode.
If both triggers are TRUE or FALSE at the same time the setpoint will remain constant.
The start value of the MOP is defined with P413:0
P400:23
0x2631:23
Motor potentiometer up
i510
i550
R/W
0:Not connected
(Reference see P400:1)
State TRUE will increase the speed setpoint in MOP-Mode.
P400:24
0x2631:24
Motor potentiometer down
i510
i550
R/W
0:Not connected
(Reference see P400:1)
State TRUE will decrease the speed setpoint in MOP-Mode.
P400:25
0x2631:25
Motor potentiometer select
i510
i550
R/W
0:Not connected
(Reference see P400:1)
Trigger to enable the MOP-Mode. After enabling the speed is controlled
by digital inputs MOP up / MOP down.
P413:0
0x4003:0
Motor pot. start mode
i510
i550
R/W
0: Last value
1: Init Value
2: Minimum Value
Defines the start setpoint value when MOP is enabled.
0: Last value
MOP starts with the last MOP set value.
1: Init Value
MOP starts with the value in P414:1 or P414:2
2: Minimum Value
MOP starts with minimum frequency (P210:0) or minimum PID value
(P605:1)
P414:1
0x4004:1
Speed
i510
i550
R/W
0.0 ... [0.0] ... 599.0 Hz
Frequency start value for MOP-Mode
Note: Only active if P413:0 is set to 1
P414:2
0x4004:2
Process controller (PID)
i510
i550
R/W
-300.00 ... [0.00] ... 300.00 PUnit
Process controller start value for MOP-Mode
Note: Only active if P413:0 is set to 1
