Lenze i510 - Output Power; Output Energy; Analog Input 1 Diagnosis; Analog Input 2 Diagnosis

6 Function & parameter description
Group 1 – Diagnostics
44 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
6.3.2 Output Power
P108:1
0x2DA2:1
Effective power
i510
i550
R
-- ... [Actual value] ... -- kW
Actual motor effective power
P108:2
0x2DA2:2
Apparent power
i510
i550
R
-- ... [Actual value] ... -- kVA
Actual motor apparent power
6.3.3 Output Energy
P109:1
0x2DA3:1
Motor
i510
i550
R
-- ... [Actual value] ... -- kWh
Estimated energy at the inverter output when the motor is being driven.
P109:2
0x2DA3:2
Generator
i510
i550
R
-- ... [Actual value] ... -- kWh
Estimated energy at the inverter output when the motor is regenerating.
6.3.4 Analog Input 1 Diagnosis
P110:1
0x2DA4:1
Percent value
i510
i550
R
-- ... [Actual value] ... -- %
Actual value of AI1 in % of the selected input range
P110:2
0x2DA4:2
Frequency value
i510
i550
R
-- ... [Actual value] ... -- Hz
Actual value of AI1 as frequency setpoint
P110:3
0x2DA4:3
Process controller value
i510
i550
R
-- ... [Actual value] ... -- PUnit
Actual value of AI1 as PID input
P110:4
0x2DA4:4
Torque value
i510
i550
R
-- ... [Actual value] ... -- %
Actual value of AI1 as torque setpoint
P110:16
0x2DA4:16
Status analog input 1
i510
i550
R
-- ... [Actual value] ... --
Bit coded status of AI1
6.3.5 Analog Input 2 Diagnosis
P111:1
0x2DA5:1
Percent value
i510
i550
R
-- ... [Actual value] ... -- %
Actual value of AI2 in % of the selected input range
P111:2
0x2DA5:2
Frequency value
i510
i550
R
-- ... [Actual value] ... -- Hz
Actual value of AI2 as frequency setpoint
P111:3
0x2DA5:3
Process controller value
i510
i550
R
-- ... [Actual value] ... -- PUnit
Actual value of AI2 as PID input
P111:4
0x2DA5:4
Torque value
i510
i550
R
-- ... [Actual value] ... -- %
Actual value of AI2 as torque setpoint
P111:16
0x2DA5:16
Status analog input 2
i510
i550
R
-- ... [Actual value] ... --
Bit coded status of AI2
6.3.6 Analog Output 1 Value
P112:1
0x2DAA:1
Voltage
i510
i550
R
-- ... [Actual value] ... -- V
Actual output voltage of A01
P112:2
0x2DAA:2
Current
i510
i550
R
-- ... [Actual value] ... -- mA
Actual output current of A01
