Lenze i510 User Manual

8 Drive Profile (Fieldbus)
Legacy Lenze Format
108 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
0x400C:5 P593:5 Lenze Legacy drive state
Bits
Function
Comments
0
Fault Locked
1
Fault
2
Start Pending
3
Identification Not Done
4
Inhibit
5
Stop
6
Switching On Sequence
7
Identification in Progress
8
Running
9
Acceleration
10
Deceleration
11
Deceleration Override
12
DC Brake
13
Flying Start
14
Current Limit
16
Sleep Mode
8.2.3 Speed setpoint / Actual Speed
Several speed command formats are also available:
P592:3
0x400B:3
Network frequency setpoint
i510
i550
R/W
0.0 ... [0.0] ... 599.0 Hz
Legacy network frequency setpoint
Scaling: 0.1 Hz unsigned (direction information comes via control word)
P592:4
0x400B:4
Network setpoint speed
i510
i550
R/W
0 ... [0] ... 50000 rpm
Legacy network speed setpoint
Scaling: RPM unsigned (direction information comes via control word)
P592:5
0x400B:5
Network setp. frequency
i510
i550
R/W
0.00 ... [0.00] ... 599.00 Hz
Legacy network frequency setpoint
Scaling: 0.01 Hz unsigned (direction information comes via control word)
P592:6
0x400B:6
Network speed setpoint
i510
i550
R/W
-599.0 ... [0.0] ... 599.0 Hz
Legacy network frequency setpoint
Scaling: 0.1 Hz signed
Several actual speed formats are also available:
P593:3
0x400C:3
Actual frequency Hz
i510
i550
R
-- ... [Actual value] ... -- Hz
Legacy actual frequency
Scaling 0.1Hz, unsigned
P593:4
0x400C:4
Actual motor speed RPM
i510
i550
R
-- ... [Actual value] ... -- rpm
Legacy actual speed
Scaling RPM, unsigned
P593:6
0x400C:6
Actual frequency
i510
i550
R
-- ... [Actual value] ... -- Hz
Legacy actual frequency
Scaling 0.01Hz, unsigned
