6 Function & parameter description
Group 1 – Diagnostics
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 45
6.3.7 Analog Output 2 Value
-- ... [Actual value] ... -- V
Actual output voltage of A02
-- ... [Actual value] ... -- mA
Actual output current of A02
6.3.8 Heatsink temperature
-- ... [Actual value] ... -- °C
Actual heatsink temperature
6.3.9 I/O Status
Bit # description:
16: Level at digital input 1
17: Level at digital input 2
18: Level at digital input 3
19: Level at digital input 4
20: Level at digital input 5
21: Level at digital input 6
22: Level at digital input 7
25: Low active - NPN
Status of digital input (Bit coded)
Display toggles between LWX/HWX
LWX Bit 0-15
HWX Bit 16 - 31
Bit # description:
0: Start Key
1: Stop Key
2: Up Key
3: Down Key
4: Enter Key
5: Escape Key
Keypad status (Bit coded)
Bit # description:
0: Relay
1: Digital output 1
2: Digital output 2
10: Charge Relay
Status of digital outputs and relay (Bit coded)
6.3.10 Process Controller Diagnosis
-- ... [Actual value] ... -- PUnit
-- ... [Actual value] ... -- PUnit
Bit # description:
0: Process controller off
1: PID output set to 0
2: PID I-component set to 0
