Preface
About this Hardware Manual
Products to which the Hardware Manual applies
1
13
EDS94SPP101 EN 10.2
1.2.2 Products to which the Hardware Manual applies
Power modules
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
E94 x x x E xxx x x xx xx xx −
Type / product range
9400 Servo Drives
Version
A = 1.
B = 2.
N = not relevant
Version
S = single−axis controller (Single Drive)
M = multi−axis controller (Multi Drive)
P = power supply module
R = regenerative power supply module
Variant
H = HighLine
N = not relevant
P = PLC
Mechanical version
E = Installation
Rated current (rounded)
e.g. 007 = 7 A, 024 = 23.5 A
Voltage class
2 = 230 V ~ / 300 V =
4 = 400 V ~ / 540 V =
Safety module in MSI (place 7 of the extension modules)
A ... F
Memory module in MMI (places 7 and 8 of the extension modules)
22 ... 44
Extension module in MXI2 (places 7 and 8 of the extension modules)
xx
Extension module in MXI1 (places 7 and 8 of the extension modules)
xx
In the case of complete devices, the type code can contain a 5−place item of information regarding the configured
installation backplane, whereby this information appears at place 19 after the separator (see places 7 to 14,
power−related accessories).
In addition, a 6−place item of information regarding an integrated motor holding brake control module can be
contained (see places 6 to 14, performance−related accessories. "N" means "Not relevant".
With the help of the type code, you can identify supplied products on the basis of the information on the nameplate.
In the product catalogue, you can find the possible configuration in order to order the product.
