Lenze L-force 9400 Hardware Manual

Regenerative power supply modules
Rated data
Operation with rated mains voltage 480 V
6

294
EDS94SPP101 EN 10.2
6.3.4 Operation with rated mains voltage 480 V
Input data (on the supply side)
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f [Hz]
3/PE AC 480 340 − 0 % ... 528 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Continuous input power
Type [V] S
L
[kVA]
E94ARNE0134
In motor mode
480 21.6
In generator mode
480 10.8
E94ARNE0244
In motor mode
480 39.0
In generator mode
480 19.5
Output data (on the DC side)
Mains Volta
g
e Volta
g
e ran
g
e Fre
q
uenc
y
ran
g
e
Voltage
U
DC
[V]
Voltage
range
U
DC
[V]
Frequency
range
f [Hz]
2/PE DC 675 480 − 0 % ... 746 + 0 % −
Output current and output power
100 % 5−s cycle 3−min cycle
Type I
DC
[A] P
DC
[kW] I
DC
[A] P
DC
[kW] I
DC
[A] P
DC
[kW]
E94ARNE0134
In motor mode
32 18.0 96 53.8 48 26.9
In generator mode
16 9.0 48 26.9 24 13.4
E94ARNE0244
In motor mode
57 32.4 171 97.3 86 48.7
In generator mode
28.5 16.2 87 48.6 44 24.3
100 % Permanent rated values
5−s cycle Cycle for the second−range
(0.5 s overload/4.5 s recovery time with 75 % of the permanent rated value)
3−min cycle Cycle for the minute−range
(60 s overload/120 s recovery time with 75 % of the permanent rated value)
