Rated data
Operation in 480−V−AC system
4

176
EDS94SPP101 EN 10.2
4.4.4 Operation in 480−V−AC system
Mains Volta
g
e Volta
g
e ran
g
e Fre
q
uenc
y
ran
g
e
Voltage
U
DC
[V]
Voltage
range
U
DC
[V]
Frequency
range
f [Hz]
2/PE DC 675 540 − 0 % ... 746 + 0 % −
Input current at I
aN8
Output power Motor power
(typical)
(without external mains
choke)
U, V, W 4−pole ASM
Type I
DC
[A] S
aN
[kVA] P
aN
[kW] P
aN
[hp]
E94AMxE0024 2.3 1.0 0.37 0.5
E94AMxE0034 3.8 1.6 0.75 1.0
E94AMxE0044 5.9 2.6 1.5 2.0
E94AMxE0074 10.6 4.6 3.0 4.0
E94AMxE0094 13.5 8.5 4.0 5.0
E94AMxE0134 18.0 10.8 5.5 7.5
E94AMxE0174 22.5 15.4 7.5 10.0
E94AMxE0244 31.1 19.4 11.0 15.0
E94AMxE0324 38.9 31.4 15.0 20.4
E94AMxE0474 62.0 38.1 22 29
E94AMxE0594 77.0 38.9 30 40
Output currents [A] at switching frequency
2 kHz 4 kHz 8 kHz 16 kHz
I
aN2
I
aM2
I
aN4
I
aM4
I
aN8
I
aM8
I
aN16
E94AMxE0024 1.9 6.0 1.9 6.0 1.3 4.2 1.0
E94AMxE0034 3.1 10.0 3.1 10.0 2.2 7.0 1.7
E94AMxE0044 5.0 16.0 5.0 16.0 3.5 11.2 2.6
E94AMxE0074 8.8 21.0 8.8 21.0 6.1 14.7 4.6
E94AMxE0094 11.7 28.0 11.7 28.0 8.2 19.6 6.1
E94AMxE0134 16.3 39.0 16.3 39.0 11.4 27.3 8.6
E94AMxE0174 20.6 49.5 20.6 49.5 14.4 34.7 10.9
E94AMxE0244 29.4 70.5 29.4 70.5 20.6 49.4 15.4
E94AMxE0324 40.0 76.8 40.0 76.8 25.9 62.1 13.0
E94AMxE0474 47.0 94.0 41.1 82.2 35.8 71.6 21.5
E94AMxE0594 59.0 118 51.6 103 35.9 71.8 21.5
I
aN2
Rated value of permanent output current at a frequency of  0 Hz
I
aM2
Maximum output current (overload current) at frequency  0 Hz
 Periodic load change of 0.5 s with I
aM2
and recovery time of 4.5 s with
75% I
aN2
I
aN4
, I
aN8,
I
aN16
Rated value of continuous output current at a frequency of  5 Hz
(reduce to 0.66 * I
aNx
for 0 ... 5 Hz)
I
aM4
, I
aM8
Maximum output current (overload current) at frequency  5 Hz
(reduce to 0.66 * I
aMx
for 0 ... 5 Hz)
 Periodic load change of 0.5 s with I
aMx
and recovery time of 4.5 s with
75% I
aNx
 Can be achieved using the setting "x kHz fixed" in C00018
bold Nominal value I
aN
4)
Depending on the heatsink temperature, the mains voltage and the motor
cable length, the switching frequency can be changed even at smaller currents.
