General data and operating conditions
4

167
EDS94SPP101 EN 10.2
4.3 General data and operating conditions
General data
Conformity and approval
Conformity
CE
2014/35/EU Low−Voltage Directive
CE 2014/30/EU EMC Directive
EAC TPTC004/2011
(TPZU004/2011)
Regarding the safety of
low−voltage equipment
Eurasian conformity
TR ZU: Technical regulation of
the tariff union
EAC TPTC020/2011
(TPZU020/2011)
Electromagnetic
compatibility of technical
products
Eurasian conformity
TR ZU: Technical regulation of
the tariff union
Approval
C
UL
US
UL61800−5−1 Industrial Control Equipment
(File No. E132659) for USA
CSA C22.2 No. 274−13 Industrial Control Equipment
(File No. E132659) for Canada
Protection of persons and device protection
Type of protection
EN 60529
IP 20
Outside the wire range of
the terminals on the
motor side
NEMA 250 Protection against accidental
contact in accordance with type
1
Insulation resistance EN 61800−5−1 Overvoltage category III
from 2000 m amsl: external measures for compliance with
the overvoltage category II are required, e.g.
 upstream connection of transformer
 upstream connection of overvoltage protection system
Control circuit isolation EN 61800−5−1 up to 2000 m amsl:
Safe mains isolation by double/reinforced insulation for
mains with neutral earthing with a rated voltage for the
external conductor/star point up to 300 V.
from 2000 m amsl:
If an overvoltage protection system is connected upstream to
the device, additional external measures are required for
maintaining the safe isolation.
Short−circuit strength EN 61800−5−1 Motor connection: with restrictions, error acknowledgement
required
Control terminals: full
Motor − protective
measures against
 Short circuit
 Earth fault
 Overvoltage
 motor stalling
 Motor overtemperature
(PTC or thermal contact, I
2
t monitoring)
Leakage current EN 61800−5−1 > 3.5 mA AC, > 10 mA DC Observe regulations and
safety instructions!
Cyclic mains switching Cyclic mains switching of 5 times in 5 minutes is permissible
without restrictions.
