8 Accessories (overview)
Note!
You can find additional information on the accessories in the catalogue to this
product series.
8.1 System overview
The following figure shows the most important components for the implementation of a
drive system with the Servo Drives 9400 product range.
On the way from the mains connection to the motor, you can see the basic principle of a
drive system on the left path. On the right path, the basic principle of a single−axis drive is
described.
In accordance with the requirements of your drive solution, your drive system can be
equipped or extended with specially adapted components.
