Lenze L-force 9400 Hardware Manual

Single−axis controllers
Rated data
Overview
3

43
EDS94SPP101 EN 10.2
3.4.1 Overview
Input data
Voltage Frequency Rated current [A]
Number of
phases
[V AC]
[V DC]
[Hz] up to +45 °C  up to +55 °C 
E94ASxE0024 230/400/480
325/565/675
50/60
0
2.1/2.1/1.8
2.6/2.6/2.3
1.6/1.6/1.4
1.9/1.9/1.7
3
−
E94ASxE0034 230/400/480
325/565/675
50/60
0
3.5/3.5/3.1
4.3/4.3/3.8
2.6/2.6/2.3
3.2/3.2/2.9
3
−
E94ASxE0044 230/400/480
325/565/675
50/60
0
5.5/5.5/4.8
6.7/6.7/5.9
4.1/4.1/3.6
5.0/5.0/4.4
3
−
E94ASxE0074 230/400/480
325/565/675
50/60
0
9.9/9.9/8.6
12.1/12.1/10.6
7.4/7.4/6.5
9.1/9.1/8.0
3
−
E94ASxE0134 230/400/480
325/565/675
50/60
0
16.8/16.8/14.7
20.6/20.6/18.0
12.6/12.6/11.0
15.5/15.5/13.5
3
−
E94ASxE0174 230/400/480
325/565/675
50/60
0
21.0/21.0/18.3
25.7/25.7/22.5
15.8/15.8/13.8
19.3/19.3/16.9
3
−
E94ASxE0244 230/400/480
325/565/675
50/60
0
29.0/29.0/25.4
35.5/35.5/31.1
21.8/21.8/19.1
26.6/26.6/23.3
3
−
E94ASxE0324 230/400/480 50/60 29.0/29.0/26.0 22.0/22.0/20.0 3
E94ASxE0474 230/400/480
325/565/675
50/60
0
43.0/43.0/39.0
71.0/71.0/62.0
32.0/32.0/29.0
53.3/53.3/46.5
3
−
E94ASxE0594 230/400/480
325/565/675
50/60
0
54.0/54.0/47.0
89.0/89.0/77.0
40.5/40.5/35.3
66.8/66.8/57.8
3
−
E94ASxE0864 230/400/480 50/60 79.0/79.0/70.0 59.0/59.0/52.0 3
E94ASxE1044 230/400/480 50/60 95.0/95.0/84.0 71.0/71.0/63.0 3
E94BSxE1454 400/480 50/60 138/138 124/124 3
E94BSxE1724 400/480 50/60 164/164 148/148 3
E94BSxE2024 400/480 50/60 192/192 173/173 3
E94BSxE2454 400/480 50/60 236/236 212/212 3
E94BSxE2924 400/480 50/60 285/285 257/257 3
E94BSxE3664 400/480 50/60 349/349 314/314 3
E94BSxE4604 400/480 50/60 436/436 392/392 3
