Lenze L-force 9400 Hardware Manual

Multi−axis controllers
Mechanical installation
Devices in the range 47 ... 59 A (22 ... 30 kW)
4

197
EDS94SPP101 EN 10.2
4.6.3 Devices in the range 47 ... 59 A (22 ... 30 kW)
SSP94Mas01
Fig. 4−11 Dimensions [mm]
Dimensions [mm] Weight
Device
size
Type a b b1 b2 e c1 d g m [kg]
E94AMHE0474
206
606 556 630 294 170 585 6.5 12.5 26.5 6
E94AMHE0594
