Regenerative power supply modules
Rated data
Overview
6

289
EDS94SPP101 EN 10.2
6.3 Rated data
6.3.1 Overview
Input data (on the supply side)
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E94ARNE0134
In motor mode
230/400/480 50/60 26/26/26 19.5/19.5/19.5 3
In generator mode
230/400/480 50/60 13/13/13 9.8/9.8/9.8 3
E94ARNE0244
In motor mode
230/400/480 50/60 47/47/47 35/35/35 3
In generator mode
230/400/480 50/60 23.5/23.5/23.5 17.6/17.6/17.6 3
 Temperature in the control cabinet
Output data (on the DC side)
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E94ARNE0134
In motor mode
325/565/675 0 (DC) 32/32/32 24/24/24 −
In generator mode
345/586/699 0 (DC) 16/16/16 12/12/12 −
E94ARNE0244
In motor mode
325/565/675 0 (DC) 57/57/57 43/43/43 −
In generator mode
325/565/699 0 (DC) 28.5/28.5/28.5 21.4/21.4/21.4 −
 Temperature in the control cabinet
