Lenze L-force 9400 Hardware Manual

Multi−axis controllers
Overview of the devices
4

166
EDS94SPP101 EN 10.2
4.2 Overview of the devices
 Note!
For reasons of clarity, device types in this manual are placed together in groups
with shared device characteristics. For example:
ƒ "Devices in the range 2 ... 24 A (0.37 ... 11 kW)" (often from project planner’s
viewpoint) or
ƒ "Device sizes 1, 2 and 3" (often from installation point of view)
The following table gives you an overview of the different device characteristics:
Type Rated current (rounded) Motor power (typ.) Device size (DS)
E94AMxE0024
E94AMxE0034
E94AMxE0044
2 A
3 A
4 A
0.37 kW
0.75 kW
1.5 kW
1
E94AMxE0074
E94AMxE0094
7 A
9 A
3.0 kW
4.0 kW
2
E94AMxE0134
E94AMxE0174
E94AMxE0244
E94AMxE0324
13 A
17 A
24 A
32 A
5.5 kW
7.5 kW
11 kW
15 kW
3
E94AMxE0474
E94AMxE0594
47 A
59 A
22 kW
30 kW
6
