Multi−axis controllers
Mechanical installation
Important notes
4
192
EDS94SPP101 EN 10.2
4.6 Mechanical installation
4.6.1 Important notes
Note!
The devices must be installed in housings (e.g. control cabinets) to meet
applicable regulations.
ƒ The mounting location must always comply with the operating conditions specified
in the technical data ( 167). Take additional measures if necessary.
ƒ The mounting plate of the control cabinet must have the following properties:
– electrically conductive
– free of lacquer
ƒ The mechanical connections must always be ensured.
ƒ A free air circulation must be ensured for dissipating the heat.
ƒ The described EMC properties are provided if the following conditions are complied
with:
– The devices are mounted according to the arrangement concept described.
– The prepared cables are used and remain unchanged.
