160
5. PARAMETERS
5.4 (E) Environment setting parameters
5.4.1 Real time clock function
The time can be set. The time can only be updated while the inverter power is ON.
The real time clock function is enabled using an optional LCD operation panel (FR-LU08).
Simple clock function
• When the year, month, day, time and minute are set in the parameters, the inverter counts the date and time. The date
and time can be checked by reading the parameters.
• The clock's count-up data is saved in the inverter's EEPROM every 10 minutes.
• Because the date and time are cleared after turning OFF the control circuit power supply, the clock function must be reset
after turning ON the power supply. Use a separate power supply, such as an external 24 V power supply, for the control
circuit of the simple clock function, and supply power continuously to this control circuit.
• In the initial setting, inverter reset is performed if supplying power to the main circuit is started when power is supplied only
to the control circuit. Then, the clock information stored in EEPROM is restored. Reset at the start of supplying power to
the main circuit can be disabled by setting Pr.30 Regenerative function selection. (Refer to page 553)
• The set clock is also used for functions such as fault history.
Pr. Name Initial value Setting range Description
1006
E020
Clock (year) 2000 (year) 2000 to 2099 Set the year.
1007
E021
Clock (month, day) 101
(January 1)
101 to 131, 201 to 228,
(229), 301 to 331, 401 to
430, 501 to 531, 601 to 630,
701 to 731, 801 to 831, 901
to 930, 1001 to 1031, 1101
to 1130, 1201 to 1231
Set the month and day.
1000 and 100 digits: January to December
10 and 1 digits: 1 to end of month (28, 29, 30 or 31)
For December 31, set "1231".
1008
E022
Clock (hour, minute) 0
(00:00)
0 to 59, 100 to 159, 200 to
259, 300 to 359, 400 to 459,
500 to 559, 600 to 659, 700
to 759, 800 to 859, 900 to
959, 1000 to 1059, 1100 to
1159, 1200 to 1259,1300 to
1359, 1400 to 1459, 1500 to
1559, 1600 to 1659, 1700 to
1759, 1800 to 1859,1900 to
1959, 2000 to 2059, 2100 to
2159, 2200 to 2259, 2300 to
2359
Set the hour and minute using the 24-hour clock.
1000 and 100 digits: 0 to 23 hours
10 and 1 digits: 0 to 59 minutes
For 23:59, set "2359".
