5.8 (M) Monitor display and monitor output signal
3
4
5
5
5
6
7
8
9
10
5.8.5 Energy saving monitor
From the estimated consumed power during commercial power supply operation, the energy saving effect by use of the inverter
can be monitored and output.
*1 For the FR-F860-00680 or lower.
*2 For the FR-F860-01080 or higher.
Pr. Name Initial value Setting range Description
52
M100
Operation panel main monitor
selection
0
(output frequency)
Refer to page 274 50: Power saving monitor
51: Cumulative power saving monitor
774
M101
Operation panel monitor
selection 1
9999
775
M102
Operation panel monitor
selection 2
776
M103
Operation panel monitor
selection 3
54
M300
CA terminal function selection 1
(output frequency)
Refer to page 284 50: Power saving monitor
158
M301
AM terminal function selection
891
M023
Cumulative power monitor digit
shifted times
9999 0 to 4 Set the number of times to shift the cumulative
power monitor digit.
The monitored value is clamped at the maximum
value.
9999 No shift.
The monitored value is cleared when it exceeds
the maximum value.
892
M200
Load factor 100% 30 to 150% Set the load factor for the commercial power
supply operation.
This is multiplied by the power consumption rate
(page 295) during commercial power supply
operation.
893
M201
Energy saving monitor
reference (motor capacity)
Inverter capacity
0.1 to 55 kW
*1
Set the motor capacity (pump capacity). Set
when calculating the power saving power rate,
average power saving rate, and power during
commercial power supply operation.
0 to 3600 kW
*2
894
M202
Control selection during
commercial power-supply
operation
0 0 Discharge damper control (fan)
1 Inlet damper control (fan)
2 Valve control (pump)
3 Commercial power supply drive (fixed value)
895
M203
Power saving rate reference
value
9999 0 Consider the value during commercial power
supply operation as 100%.
1 Consider Pr.893 setting as 100%.
9999 No function
896
M204
Power unit cost 9999 0 to 500 Set the power unit cost. The power cost savings
are displayed on the energy saving monitor.
9999 No function
897
M205
Power saving monitor average
time
9999 0 Average of 30 minutes
1 to 1000 h Average of the set time
9999 No function
898
M206
Power saving cumulative
monitor clear
9999 0 Cumulative monitor value clear
1 Cumulative monitor value hold
10 Continue accumulation
(communication data upper limit 9999)
9999 Continue accumulation
(communication data upper limit 65535)
899
M207
Operation time rate (estimated
value)
9999 0 to 100% This value is used for calculating the annual
power saving amount. Set the annual operation
ratio (consider 365 days ï‚´ 24h as 100%).
9999 No function
