284
5. PARAMETERS
5.8 (M) Monitor display and monitor output signal
5.8.3 Monitor display selection for terminals CA and AM
The monitored status can be output as the following items: analog voltage (terminal AM), analog current (terminal CA).
The signal (monitored item) to be output to terminal CA and terminal AM can be selected.
*1 FR-F860-00680 or lower.
*2 FR-F860-01080 or higher.
*3 Function assigned to Pr.185 JOG terminal function selection.
Monitor description list (Pr.54, Pr.158)
•Set Pr.54 CA terminal function selection for the monitor to be output to the terminal CA (analog current output).
•Set Pr.158 AM terminal function selection for the monitor to be output to the terminal AM (analog voltage output). Output
with a negative sign can be made (-10 VDC to +10 VDC) from the terminal AM. in the [Negative (-) output] indicates the
output value is negative at the terminal AM. (For setting of the output with/without minus sign, refer to page 274.)
• Refer to the following table and set the monitor to be displayed. (Refer to page 275 for the monitor description.)
Pr. Name Initial value Setting range Description
54
M300
CA terminal function selection 1
(output
frequency)
1 to 3, 5 to 14, 17, 18,
21, 24, 34, 50, 52, 53,
61, 62, 67, 69, 70, 85,
87 to 90, 92, 93, 95, 98
Select the monitored item to be output to the
terminal CA.
158
M301
AM terminal function selection 1 to 3, 5 to 14, 17, 18,
21, 24, 34, 50, 52 to 54,
61, 62, 67, 69, 70, 86 to
96, 98
Select the monitored item to be output to the
terminal AM.
55
M040
Frequency monitoring reference 60 Hz 0 to 590 Hz Set the full-scale value when outputting the
frequency monitor value to terminals CA and
AM.
56
M041
Current monitoring reference Inverter rated
current
0 to 500 A
*1
Set the full-scale value when outputting the
output current monitor value to terminals CA
and AM.
0 to 3600 A
*2
866
M042
Torque monitoring reference 150% 0 to 400% Set the full-scale value when outputting the
torque monitor value to terminals CA and AM.
290
M044
Monitor negative output
selection
0 0 to 7 Set the availability of output with a minus sign
for the terminal AM, the operation panel
display, or monitoring via communication.
(Refer to page 282)
291
D100
Pulse train I/O selection 0 0 The JOG signal is assigned to terminal
JOG.
*3
1 Pulse train input is assigned to terminal JOG.
Monitor item Increment and
unit
Pr.54 (CA)
Pr.158 (AM)
setting
Terminal CA/AM
full-scale value
Negative
(-) output
Remarks
Output frequency 0.01 Hz 1 Pr.55
*3
Output current
*2
0.01 A/0.1 A
*1
2 Pr.56
Output voltage 0.1 V 3 1000 V
Frequency setting value 0.01 Hz 5 Pr.55
Running speed 1 (r/min) 6 Value is Pr.55 converted
by Pr.37, Pr.144. (Refer
to page 272.)
*3
Refer to page 272 for the
running speed monitor.
Motor torque 0.1% 7 Pr.866
Converter output voltage
*2
0.1 V 8 1000 V
— — 9 — For manufacturer setting. Do
not set.
Electronic thermal O/L
relay load factor
0.1% 10 Electronic thermal O/L
relay operation level
(100%)
Output current peak value
0.01 A/0.1 A
*1
11 Pr.56
Converter output voltage
peak value
0.1 V 12 1000 V
Input power 0.01 kW/0.1
kW
*1
13 Inverter rated power 2
