5.9 (T) Multi-Function Input Terminal Parameters
3
4
5
5
5
6
7
8
9
10
5.9 (T) Multi-Function Input Terminal Parameters
Purpose Parameter to set Refer to
page
To inverse the rotation direction with
the voltage/current analog input
selection (terminals 1, 2, and 4)
Analog input selection P.T000, P.T001 Pr.73, Pr.267 318
To assign functions to analog input
terminals
Terminal 1 and terminal 4
function assignment
P.T010, P.T040 Pr.858, Pr.868 322
To adjust the main speed by the analog
auxiliary input
Analog auxiliary input and
compensation (addition
compensation and override
functions)
P.T000, P.T021,
P.T041, P.T050,
P.T051
Pr.73, Pr.242, Pr.243,
Pr.252, Pr.253
323
To eliminate noise on analog inputs Analog input filter P.T002, P.T003,
P.T005, P.T007
Pr.74, Pr.822, Pr.832,
Pr.849
326
To adjust analog input frequency/
voltage (current) (calibration)
Frequency setting voltage
(current) bias and gain
P.T100 to P.T103,
P.T200 to P.T203,
P.T400 to P.T403,
P.M043
Pr.125, Pr.126,
Pr.241, Pr.902 to
Pr.905, Pr.917 to
Pr.918
328
To adjust voltage (current) of stall
prevention operation level (calibration)
Stall prevention operation
level setting voltage (current)
bias and gain
P.T110 to P.T113,
P.T410 to P.T413,
P.M043
Pr.241, Pr.919 to
Pr.920, Pr.932 to
Pr.933
333
To continue operating at analog current
input loss
4-mA input check P.T052 to P.T054 Pr.573, Pr.777, Pr.778 338
To assign functions to input terminals Input terminal function
selection
P.T700 to P.T711,
P.T740
Pr.178 to Pr.189,
Pr.699
343
To change the input specification (NO/
NC contact) of input signals
Output stop signal (MRS)
input selection
P.T720 Pr.17 346
Inverter run enable signal
(X10) input selection
P.T721 Pr.599 554
Power failure stop external
signal (X48) input selection
P.T722 Pr.606 461
To enable the second function only
during the constant speed
RT signal application period
selection
P.T730 Pr.155 348
To assign start and forward/reverse
commands to different signals
Start signal (STF/STR)
operation selection
P.G106 Pr.250 550
