5. PARAMETERS
5.4 (E) Environment setting parameters
3
4
5
5
5
6
7
8
9
10
5.4.12 Setting multiple parameters as a batch
Parameter settings are changed as a batch. Those include communication parameter settings for the Mitsubishi Electric’s
human machine interface (GOT) connection and the parameter setting for the rated frequency settings of 50 Hz/60 Hz and
acceleration/deceleration time.
*1 The read value is always "9999".
Automatic parameter setting (Pr.999)
• Select which parameters to automatically set from the table below, and set them in Pr.999. Multiple parameter settings are
changed automatically. Refer to page 175 for the list of parameters that are changed automatically.
NOTE
• If the automatic setting is performed with Pr.999 or the automatic parameter setting mode, the settings including the
changed parameter settings (changed from the initial setting) will be automatically changed. Before performing the
automatic setting, confirm that changing the parameters will not cause any problem.
Pr. Name Initial value Setting range Description
999
E431
Automatic parameter setting
9999
*1
1 Standard PID display setting
2 Extended PID display setting
10 GOT initial setting (PU
connector)
"Controller
Type" in GOT:
FREQROL 500/
700/800,
SENSORLESS
SERVO
11 GOT initial setting (RS485
terminals)
12 GOT initial setting (PU
connector)
"Controller
Type" in GOT:
FREQROL 800
(Automatic
Negotiation)
13 GOT initial setting (RS-485
terminal)
20 50 Hz rated frequency
21 60 Hz rated frequency
9999 No action
Pr.999
Setting
Description
1 Sets the standard monitor indicator setting of PID control.
2 Automatically sets the monitor indicator for PID control.
10 Automatically sets the communication parameters for the GOT connection with a PU connector ("Controller Type" in GOT:
FREQROL 500/700/800, SENSORLESS SERVO)
11 Automatically sets the communication parameters for the GOT connection with RS-485 terminals ("Controller Type" in GOT:
FREQROL 500/700/800, SENSORLESS SERVO)
12 Automatically sets the communication parameters for the GOT connection with a PU connector ("Controller Type" in GOT:
FREQROL 800 (Automatic Negotiation))
13 Automatically sets the communication parameters for the GOT connection with RS-485 terminals ("Controller Type" in GOT:
FREQROL 800 (Automatic Negotiation))
20 50 Hz rated frequency Sets the related parameters of the rated frequency according to the power supply frequency
21 60 Hz rated frequency
