5. PARAMETERS
5.9 (T) Multi-Function Input Terminal Parameters
3
4
5
5
5
6
7
8
9
10
5.9.6 Bias and gain for voltage (current) setting of stall
prevention operation level
The magnitude (slope) of the stall prevention operation level can be set as desired in relation to the analog signal (0 to 5 VDC,
0 to 10 VDC, or 4 to 20 mA).
Use Pr.73 Analog input selection or Pr.267 Terminal 4 input selection to switch among input 0 to 5 VDC, 0 to 10 V, and 4
to 20 mA. (Refer to page 318.)
Changing the function of analog input terminal
• The initial value for terminal 1 used as analog input is set to speed setting auxiliary (speed limit auxiliary), and terminal 4
is set to speed command. To use the analog input terminal to input the stall prevention operation level, set Pr.868 Terminal
1 function assignment and Pr.858 Terminal 4 function assignment to change the function. (Refer to page 322.)
Pr. Name Initial
value
Setting
range
Description
919
T110
Terminal 1 bias command (torque) 0% 0 to 400% Set the stall prevention operation level of the bias side of
terminal 1 input.
919
T111
Terminal 1 bias (torque) 0% 0 to 300% Set the converted % on bias side voltage of terminal 1
input.
920
T112
Terminal 1 gain command (torque) 150% 0 to 400% Set the stall prevention operation level of the gain
(maximum) of terminal 1 input.
920
T113
Terminal 1 gain (torque) 100% 0 to 300% Set the converted % on the gain side voltage of terminal
1 input.
932
T410
Terminal 4 bias command (torque) 0% 0 to 400% Set the stall prevention operation level of the bias side of
terminal 4 input.
932
T411
Terminal 4 bias (torque) 20% 0 to 300% Set the converted % on bias side current (voltage) of
terminal 4 input.
933
T412
Terminal 4 gain command (torque) 150% 0 to 400% Set the stall prevention operation level of the gain
(maximum) of terminal 4 input.
933
T413
Terminal 4 gain (torque) 100% 0 to 300% Set the converted % on gain side current (voltage) of
terminal 4 input.
241
M043
Analog input display unit switchover 0 0 % display Select the unit for analog input display.
1V/mA display
