5. PARAMETERS
5.9 (T) Multi-Function Input Terminal Parameters
5.9.5 Frequency setting voltage (current) bias and gain
The degree (incline) of the output frequency to the frequency setting signal (0 to 5 VDC, 0 to 10 V or 4 to 20 mA) is selectable
to a desired amount.
Use Pr.73 Analog input selection, Pr.267 Terminal 4 input selection, or the voltage/current input switch to switch among
input 0 to 5 VDC, 0 to 10 V, and 4 to 20 mA. (Refer to page 318)
Pr. Name Initial value Setting
range
Description
902
T200
Terminal 2 frequency setting bias
frequency
0 Hz 0 to 590 Hz Set the terminal 2 input bias side frequency.
902
T201
Terminal 2 frequency setting bias 0% 0 to 300% Set the converted % on the bias side voltage
(current) of the terminal 2 input.
125
T022
903
T202
Terminal 2 frequency setting gain
frequency
60 Hz 0 to 590 Hz Set the terminal 2 input gain (maximum)
frequency.
903
T203
Terminal 2 frequency setting gain 100% 0 to 300% Set the converted % on the gain side voltage
(current) of the terminal 2 input.
904
T400
Terminal 4 frequency setting bias
frequency
0 Hz 0 to 590 Hz Set the terminal 4 input bias side frequency.
904
T401
Terminal 4 frequency setting bias 20% 0 to 300% Set the converted % on the bias side current
(voltage) of terminal 4 input.
126
T042
905
T402
Terminal 4 frequency setting gain
frequency
60 Hz 0 to 590 Hz Set the terminal 4 input gain (maximum)
frequency.
905
T403
Terminal 4 frequency setting gain 100% 0 to 300% Set the converted % on gain side current (voltage)
of terminal 4 input.
917
T100
Terminal 1 bias frequency (speed) 0 Hz 0 to 590 Hz Set the terminal 1 input bias side frequency
(speed). (speed limit)
917
T101
Terminal 1 bias (speed) 0% 0 to 300% Set the converted % on bias side voltage of
terminal 1 input. (speed limit)
918
T102
Terminal 1 gain frequency (speed) 60 Hz 0 to 590 Hz Set the terminal 1 input gain (maximum)
frequency (speed). (speed limit)
918
T103
Terminal 1 gain (speed) 100% 0 to 300% Set the converted % on the gain side voltage of
terminal 1 input. (speed limit)
241
M043
Analog input display unit
switchover
0 0 % display Select the unit for analog input
display
1V/mA display
