5. PARAMETERS
5.9 (T) Multi-Function Input Terminal Parameters
5.9.2 Analog input terminal (terminal 1, 4) function assignment
The analog input terminal 1 and terminal 4 functions are set and changeable with parameters.
• Concerning terminal 1 and terminal 4 used for analog input, the frequency (speed) command, stall prevention operation
level input, and other similar commands are usable. The functions available are different depending on Pr.868 Terminal
1 function assignment, Pr.858 Terminal 4 function assignment as shown in the table below.
―: No function
*1 Invalid when Pr.868 = "4"
• When Pr.868 = "4" (stall prevention), the terminal 4 function is enabled whether the AU terminal is turned ON/OFF.
Pr. Name Initial value Setting range Description
868
T010
Terminal 1 function assignment 0 0, 4, 9999 Select the terminal 1 function (Refer to the
table below.)
858
T040
Terminal 4 function assignment 0 0, 4, 9999 Select the terminal 4 function (Refer to the
table below.)
Setting
value
Terminal 1 function (Pr.868) Terminal 4 function (Pr.858)
0
(initial value)
Frequency setting auxiliary Frequency command (AU signal-
ON)
4 Stall prevention operation level
input
Stall prevention operation level
input
*1
9999 ――
