454
5. PARAMETERS
5.11 (A) Application parameters
5.11.13 Offline auto tuning for a frequency search
During V/F control, the accuracy of the "frequency search", which is used to detect the motor speed for the automatic restart
after instantaneous power failure and flying start, can be improved.
*1 For the FR-F860-00680 or lower.
*2 For the FR-F860-01080 or higher.
*3 The same operation is performed for the both settings.
Pr. Name Initial
value
Setting range Description
162
A700
Automatic restart after
instantaneous power failure
selection
0
0 (2)
*3
,
1000 (1002)
*3
Frequency search only performed at the first start
1, 1001 Reduced voltage start only at the first start
(no frequency search)
3, 1003 Frequency search only performed at the first start
(reduced impact restart)
10 (12)
*3
,
1010 (1012)
*3
Frequency search at every start
11, 1011 Reduced voltage start at every start (no frequency
search)
13, 1013 Frequency search at every start (reduced impact
restart)
298
A711
Frequency search gain 9999 0 to 32767 The offline auto tuning automatically sets the gain
required for the frequency search.
9999 Uses the constant value of standard motor.
560
A712
Second frequency search gain 9999 0 to 32767 The offline auto tuning automatically sets the gain
required for the frequency search of the second motor.
9999 Uses the constant value of standard motor.
96
C110
Auto tuning setting/status 0 0 No offline auto tuning.
1, 101 Perform offline auto tuning for the Advanced magnetic
flux vector control. (Refer to page 353.)
11 Performs offline auto tuning without rotating the motor
(V/F control).
90
C120
Motor constant (R1) 9999
0 to 50 Ω, 9999
*1
Tuning data
(The value measured by offline auto tuning is
automatically set.)
9999: Uses the constant value of standard motor.
0 to 400 mΩ, 9999
*2
463
C210
Second motor auto tuning
setting/status
0 0 No auto tuning for the second motor.
1, 101 Performs offline auto tuning for the second motor.
(Refer to page 353.)
11 Performs offline auto tuning without rotating the
second motor (V/F control).
458
C220
Second motor constant (R1) 9999
0 to 50 Ω, 9999
*1
Tuning data of the second motor
(same as Pr.90)
0 to 400 mΩ, 9999
*2
To Next Page
