9. APPENDIX
9.2 Parameters (functions) and instruction codes under different control methods
3
4
5
5
5
5
5
5
9
10
9.2 Parameters (functions) and instruction codes
under different control methods
*1 Instruction codes are used to read and write parameters in accordance with the Mitsubishi inverter protocol of RS-485 communication.
(For RS-485 communication, refer to page 483.)
*2 Function availability under each control method is shown as below:
: Available
ï‚´: Not available
*3 For "parameter copy", "parameter clear", and "all parameter clear", "" indicates the function is available, and "" indicates the function is not
available.
*4 Communication parameters that are not cleared by parameter clear or all clear (H5A5A or H55AA) via communication.
*5 When a communication option is installed, parameter clear (lock release) during password lock (Pr.297 ≠"9999") can be performed only from the
communication option.
*6 Reading and writing via the PU connector are available.
Symbols in the table indicate parameters that operate when the options are connected.
FR-A8AR, FR-A8AX, FR-A8AY, FR-A8AVP, FR-A8NC, FR-A8NCE, FR-A8NCG, FR-A8ND,
FR-A8NF, FR-A8NP
Pr. Name Instruction
code
*1
Control method
*2
Parameter
Read
Write
Extended
Copy
*3
Clear
*3
All clear
*3
0 Torque boost 00 80 0  
1 Maximum frequency 01 81 0   
2 Minimum frequency 02 82 0   
3 Base frequency 03 83 0  
4 Multi-speed setting (high speed) 04 84 0   
5 Multi-speed setting (middle speed) 05 85 0   
6 Multi-speed setting (low speed) 06 86 0   
7 Acceleration time 07 87 0   
8 Deceleration time 08 88 0   
9 Electronic thermal O/L relay 09 89 0   
10 DC injection brake operation frequency 0A 8A 0   
11 DC injection brake operation time 0B 8B 0   
12 DC injection brake operation voltage 0C 8C 0  
13 Starting frequency 0D 8D 0   
14 Load pattern selection 0E 8E 0  
15 Jog frequency 0F 8F 0   
16 Jog acceleration/deceleration time 10 90 0   
17 MRS input selection 11 91 0   
18 High speed maximum frequency 12 92 0   
19 Base frequency voltage 13 93 0  
20 Acceleration/deceleration reference frequency 14 94 0   
21 Acceleration/deceleration time increments 15 95 0   
22 Stall prevention operation level 16 96 0   
23 Stall prevention operation level compensation factor at
double speed
17 97 0  
24 Multi-speed setting (speed 4) 18 98 0   
25 Multi-speed setting (speed 5) 19 99 0   
26 Multi-speed setting (speed 6) 1A 9A 0   
27 Multi-speed setting (speed 7) 1B 9B 0   
28 Multi-speed input compensation selection 1C 9C 0   
29 Acceleration/deceleration pattern selection 1D 9D 0   
30 Regenerative function selection 1E 9E 0   
31 Frequency jump 1A 1F 9F 0   
32 Frequency jump 1B 20 A0 0   
33 Frequency jump 2A 21 A1 0   
34 Frequency jump 2B 22 A2 0   
Magnetic fluxMagnetic fluxMagnetic flux
PM
PM
