5. PARAMETERS
5.8 (M) Monitor display and monitor output signal
3
4
5
5
5
6
7
8
9
10
5.8 (M) Monitor display and monitor output signal
Purpose Parameter to set Refer to
page
To display the motor speed.
To set to rotations per minute.
Speed display and rotations
per minute setting
P.M000 to P.M002 Pr.37, Pr.144, Pr.505 272
To change the monitored item on the
operation panel and the parameter unit
Operation panel monitored
item selection,
clearing the cumulative
monitor
P.M020 to P.M023,
P.M030, P.M031,
P.M044, P.M045,
P.M050 to P.M052,
P.M100 to P.M103
Pr.52, Pr.170,
Pr.171, Pr.268,
Pr.290, Pr.563,
Pr.564, Pr.774 to
Pr.776, Pr.891,
Pr.1018, Pr.1106 to
Pr.1108
274
To change the monitored item output
from the terminals CA and AM
Terminal CA function
selection
P.M040 to P.M042,
P.M044, P.M300,
P.M301, P.D100
Pr.54, Pr.55, Pr.56,
Pr.158, Pr.290,
Pr.291, Pr.866
284
To adjusting the terminal CA and AM
output
Terminal CA, AM calibration P.M310, P.M320,
P.M321, P.M330 to
P.M334
Pr.867, Pr.869,
Pr.900, Pr.901,
Pr.930, Pr.931
288
To check the effects of energy saving Energy saving monitor P.M023, P.M100,
P.M200 to P.M207,
P.M300, P.M301
Pr.52, Pr.54, Pr.158,
Pr.891 to Pr.899
291
To assign functions to the output
terminals
Output terminal function
assignment
P.M400 to P.M406,
P.M410 to P.M416,
P.M420 to P.M422,
P.M431
Pr.190 to Pr.196,
Pr.289, Pr.313 to
Pr.322
297
To detect the output frequency Up-to-frequency sensitivity
Output frequency detection
Low speed detection
P.M440 to P.M444 Pr.41 to Pr.43, Pr.50,
Pr.870
305
To detect the output current Output current detection
Zero current detection
P.M433, P.M460 to
P.M464
Pr.150 to Pr.153,
Pr.166, Pr.167
307
To detecting the output torque Output torque detection P.M470 Pr.864 309
To use the remote output function Remote output P.M500 to P.M502 Pr.495 to Pr.497 310
To use the analog remote output function Analog remote output P.M530 to P.M534 Pr.655 to Pr.659 312
To output the fault code from a terminal Fault code output function P.M510 Pr.76 314
To detect the specified output power Pulse train output of output
power
P.M520 Pr.799 315
To detect the control circuit temperature Control circuit temperature
monitor
P.M060 Pr.663 316
