6.1 Data Type and Storage Location
6 - 1
6
DATA CONTROL
6. DATA CONTROL
A system application, project data (screen data), or alarm data which is written in the GOT or data storage can be displayed,
and the data can be transferred between the GOT and data storage.
The format of the data storage is also possible.
6.1 Data Type and Storage Location
■1. System
The data storage location and transferring (write/read) route for each data type are shown below.
Also, the data storage locations are shown below.
*1 The USB memory can be used from Utility.
➠ 7.3.2 Installing using the data control function (Utility)
*2 When using the project data stored in the Built-in SD card (A drive) with the GOT, hold the SD card installed to the GOT.
For the USB memory, store the project data to the Built-in SD card (A drive) or built-in flash memory (C drive).
Item Data type Storage location
BootOS • Built in flash memory (C drive)
*1
Basic system application
• Built-in SD card (A drive)
• Built in flash memory (C drive)
*2
PLC communication driver
System application (Extended function)
*1
Project data
(Including recipe setting, alarm conditions, time action, and GOT setup.)
• Built-in SD card (A drive)
*2
• Built-in flash memory (C drive)
*2
GOT
C drive
(Built-in flash memory)
System
application
BootOS
Install
Download
Install
Download
PC
GT Designer3
Project
data
System
application
BootOS
Project
data
System
application
BootOS
Project
data
A drive
(Standard SD card),
B drive
(Extended memory card)
E drive
(USB drive)
USB memory
(when installed in GOT)
Write
SD card
(when installed
in PC)
Inserting/
Removing
USB memory
(when installed
in PC)
Upload
Project
data
Project
data
Copy files on
Windows
Project
data + OS
Upload
SD card
(when installed in GOT)
BootOS
BootOS
System
application
Project
data
