12.1 Display Settings
12 - 1
DISPLAY AND OPERATION SETTINGS (GOT SET UP)
12
12. DISPLAY AND OPERATION SETTINGS (GOT SET UP)
The setting screens related to the display or operation can be displayed from the utility screen.
In the setting screen for display and the setting screen for operation, the following settings can be set.
12.1 Display Settings
12.1.1 Display functions
Setting regarding display is possible.
The items which can be set are described below. If touch the each item part, the respective setting becomes possible.
POINT
POINT
POINT
(1) Display setting by GT Designer3
Set title display period, screen save time and screen save backlight by selecting [Common]
→ [GOT Environmental Setting] → [GOT Setup...] on GT Designer3.
When change a part of the setting, change the setting by the GOT display setting after
downloading the project data.
➠ GT Designer3 (GOT2000) Help
(2) Screen save time
By using the system information function, the screen save function can forcibly enabled from
a controller (Forced Screen Saver Disable Signal) or the screen saving time set in the utility
can be disabled (Automatic Screen Saver Disable Signal).
➠ GT Designer3 (GOT2000) Help
Item Description Reference
Display settings
Setting the startup screen display time and screen saving time
➠ 12.1.1
Brightness
Operation
Setting buzzer volume, window move buzzer, and key reaction
➠ 12.2.3
Touch panel calibration
➠ 12.2.4
Utility call key
➠ 12.2.4
Item Description Setting range
Opening time
The title display period at the main unit boot can be set.
0 to 60 seconds
(At factory shipment: 1 seconds)
Screen save time
The period from the user stops the touch panel
operation till the screen save function starts can be set.
0 to 60 minutes
(At factory shipment: 0 minute)
Brightness
Brightness can be adjusted.
➠ ■2. Brightness
-
