 Reference Parameters: d
Preset Reference: d1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Fac-
tory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Regis-
ter
Pag
e
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
d1-01
Frequency refer-
ence 1
Sets the frequency reference.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
280H 6-5
Reference 1
0 to
100.00
%
---
A
0.00 %
d1-02
Frequency refer-
ence 2
Sets the frequency reference
when multi-step speed command
1 is ON for a multi-function
input.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
281H 6-5
Reference 2
0 to
100.00
%
---
A
0.00 %
d1-03
Frequency refer-
ence 3
Sets the frequency reference
when multi-step speed command
2 is ON for a multi-function
input.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
282H 6-5
0 to
100.00
%
---
A
0.00 %
Reference 3
d1-04
Frequency refer-
ence 4
Sets the frequency reference
when multi-step speed com-
mands 1 and 2 are ON for multi-
function inputs.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
283H 6-5
Reference 4
0 to
100.00
%
---
A
0.00 %
d1-05
Frequency refer-
ence 5
Sets the frequency when multi-
step speed command 3 is ON for
a multi-function input.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
284H 6-5
Reference 5
0 to
100.00
%
---
A
0.00 %
d1-06
Frequency refer-
ence 6
Sets the frequency reference
when multi-step speed com-
mands 1 and 3 are ON for multi-
function inputs.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
285H 6-5
Reference 6
0 to
100.00
%
---
A
0.00 %
d1-07
Frequency refer-
ence 7
Sets the frequency reference
when multi-step speed com-
mands 2 and 3 are ON for multi-
function inputs.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
286H 6-5
Reference 7
0 to
100.00
%
---
A
0.00 %
d1-08
Frequency refer-
ence 8
Sets the frequency reference
when multi-step speed com-
mands 1, 2, and 3 are ON for
multi-function inputs.
0 to
120.00
*1,*2
i
Yes
A
0.00
Hz
A
0.00
Hz
A
0.00
Hz
-
287H 6-5
Reference 8
0 to
100.00
%
---
A
0.00 %
d1-09
Nominal speed
Sets the frequency reference
when the nominal speed is
selected by a digital input.
0 to
120.00
*1,*2
i
Yes
Q
50.00
Hz
Q
50.00
Hz
Q
50.00
Hz
-
288H
6-7
6-8
Nomin Speed vn
0 to
100.00
%
---
Q
100.00
%
