Omron VARISPEED L7 User Manual

3-5
3
 Inverter Modes
The Inverter's parameters and monitoring functions are organized in five groups which make it easy to read
and adjust parameters.
The 5 modes and their primary functions are shown in the Table 3.2.
Table 3.2 Modes
Mode Primary function(s)
Drive mode
Use this mode to start/stop the inverter, to monitor values such as the frequency ref-
erence or output current and to read out fault informations or the fault history.
Quick programming mode Use this mode to read and set the basic parameters.
Advanced programming mode Use this mode to read and set all parameters.
Verify mode
Use this mode to read and set parameters that have been changed from their factory-
set values.
Autotuning mode
*1
*1. Always perform autotuning with the motor before operating in the vector control modes.
Use this mode when using a motor with unknown motor data in the vector control
modes. The motor data are measured/calculated and set automatically.
This mode can also be used to measure the motor line-to-line resistance only.
