6-63
6
Motor Rated Power (E5-02)
Set E5-02 to the rated power value as written on the motor nameplate or in the motor data sheet.
Motor Rated Current (E5-03)
Set E5-03 to the motor rated current as written on the motor nameplate or in the motor data sheet.
Number of Motor Poles Setting (E5-04)
Set the number of motor poles as written on the motor nameplate or in the motor data sheet.
Motor Line-to-Line Resistance Setting (E5-05)
Set the motor line-to-line resistance as written in the motor data sheet. Alternatively a measured value can be
entered.
Motor d- and q-Axis Inductance (E5-06, E5-07)
Set the q-axis and d-axis inductance value in mH as written on the nameplate or the motor data sheet.
Motor Voltage Constant (E5-09)
Set the motor voltage constant k
e
is set in mV as written on the nameplate or the motor data sheet.
îš‹ Motor Rotation Direction Change
If the motor operates in the wrong direction with an Up or Down command, the direction can be changed by
parameter S3-08.
îš„Related Parameters
îš„Change Motor Direction in V/f or Open Loop Vector Control
To change the motor rotation direction without changing the wiring, parameter S3-08 can be changed.
• If S3-08 = 0 the output phase order will be U-V-W
• If S3-08 = 1 the output phase order will be U-W-V
îš„Change Motor Direction in Closed Loop Vector Control
If Closed Loop Vector Control for IM or PM is used, besides changing parameter S3-08 the encoder direction
has to be changed by setting F1-05.
Parameter
No.
Name
Factory
Setting
Change
during
Operation
Control Methods
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
F1-05 Encoder direction change No No No Q Q
S3-08Output phase order 0 No AAAA
IMPORTANT
If Closed Loop Vector Control for PM motors is used, always perform an encoder offset tuning
after parameter S3-08 of F1-05 has been changed.
